Disk of Yesteryear Compared to Today’s SSD Drives

by Wayne Leutwyler



In my [last blog post](https://www.percona.com/ community-blog/2019/08/01/how-to-build-a-percona-server-stack-on-a-raspberry-pi-3/) I showed you how to get the entire Percona “Stack" up and running on a Raspberry Pi. This time around, I would like to show the impact on performance between using an SSD hard disk and a standard hard disk.

Disk performance is a key factor in Percona Server for MySQL (or any RDB platform) performance on a Raspberry Pi 4.

Test set up

Each test below was run three times per Hard Disk and I took the best of the three for comparison. Hardware

  • Raspberry Pi 4+ with 4GB ram.
  • Disk 1: USB3 Western Digital My Passport Ultra, 1TB
  • Disk 2: USB3 KEXIN 240GB Portable External SSD Drive

Hardware stayed consistent during test, except for the hard disk that were switched from KEXIN to Western Digital drive. Software

  • Raspbian Buster
  • Persona Server Version: 5.7.27-30 built from source. See the above BLOG for install instructions.
  • Sysbench 1.0.17

Sample my.cnf

[mysqld]
port = 3306
socket = /var/lib/mysql/mysql.sock
pid-file = /var/lib/mysql/mysqld.pid
basedir = /usr/local/mysql
datadir = /data0/mysql/data
tmpdir = /data0/mysql/tmp
general_log_file = /var/log/mysql/mysql-general.log
log-error = /var/log/mysql/mysqld.log
slow_query_log_file = /var/log/mysql/log/slow_query.log
slow_query_log = 0 # Slow query log off
lc-messages-dir = /usr/local/mysql/share
plugin_dir = /usr/local/mysql/lib/mysql/plugin
log-bin = /data0/mysql/binlog/mysql-bin
sync_binlog = 1
expire_logs_days = 5
server-id = 1
binlog_format = mixed
max_allowed_packet = 64M
max_connections = 50
max_user_connections = 40
query_cache_size=0
query_cache_type=0

innodb_data_home_dir = /data0/mysql/data
innodb_log_group_home_dir = /data0/mysql/data
innodb_log_files_in_group = 2
innodb_buffer_pool_size = 1536M
innodb_log_file_size = 64M
innodb_log_buffer_size = 8M
innodb_flush_log_at_trx_commit = 2
#innodb_flush_log_at_trx_commit = 0
innodb_lock_wait_timeout = 50
innodb_flush_method = O_DIRECT
innodb_file_per_table = 1
innodb_buffer_pool_instances = 1
skip-name-resolve=0
thread_pool_size=20
innodb_temp_data_file_path = ../tmp/ibtmp1:12M:autoextend:max:8G

Sysbench MySQL test prep step:

sysbench --db-driver=mysql —mysql-db=sbtest --oltp-table-size=500000 --oltp-tables-count=10 --threads=8 --mysql-host= --mysql-port=3306 --mysql-user= --mysql-password=
/usr/share/sysbench/tests/include/oltp_legacy/parallel_prepare.lua run

Test 1

This was done using the: KEXIN 240GB Portable External SSD Drive. Sysbench command:

sysbench --db-driver=mysql --mysql-db=sbtest --report-interval=2 --mysql-table-engine=innodb --oltp-table-size=500000 --oltp-tables-count=10 --oltp-test-mode=complex --threads=10 --time=150 —mysql-host= --mysql-port=3306 —mysql-user= —mysql-password= /usr/share/sysbench/tests/include/oltp_legacy/oltp.lua run

Output:

SQL statistics:
    queries performed:
        read:                            486542
        write:                           139012
        other:                           69506
        total:                           695060
    transactions:                        34753  (231.62 per sec.)
    queries:                             695060 (4632.45 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)
General statistics:
    total time:                          150.0362s
    total number of events:              34753

Latency (ms):
         min:                                   20.28
         avg:                                   43.16
         max:                                   94.32
         95th percentile:                       57.87
         sum:                              1500044.61

Threads fairness:
    events (avg/stddev):           3475.3000/368.77
    execution time (avg/stddev):   150.0045/0.01

As you can see the performance with the KEXIN (SSD) Drive was pretty good:

transactions:                        34753  (231.62 per sec.)
queries:                             695060 (4632.45 per sec.)

Test 2

This was done using the: Western Digital My Passport Ultra 1TB drive.

SQL statistics:
    queries performed:
        read:                            60984
        write:                           17424
        other:                           8712
        total:                           87120
    transactions:                        4356   (29.00 per sec.)
    queries:                             87120  (579.94 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)

General statistics:
    total time:                          150.2160s
    total number of events:              4356

Latency (ms):
         min:                                   23.26
         avg:                                  344.75
         max:                                 1932.12
         95th percentile:                      733.00
         sum:                              1501739.03

Threads fairness:
    events (avg/stddev):           435.6000/5.71
    execution time (avg/stddev):   150.1739/0.05

As you can see the performance on the Western Digital Drive was really bad:

transactions:                        4356   (29.00 per sec.)
queries:                             87120  (579.94 per sec.)

Disk IO Tests

KEXIN:

Operations performed:  208123 Read, 138748 Write, 443904 Other = 790775 Total
Read 3.1757Gb  Written 2.1171Gb  Total transferred 5.2928Gb  (18.066Mb/sec)
 1156.24 Requests/sec executed

Test execution summary:
    total time:                          300.0004s
    total number of events:              346871
    total time taken by event execution: 113.1569
    per-request statistics:
         min:                                  0.02ms
         avg:                                  0.33ms
         max:                                 31.07ms
         approx.  95 percentile:               0.60ms

Threads fairness:
    events (avg/stddev):           346871.0000/0.00
    execution time (avg/stddev):   113.1569/0.00

Western Digital:

Operations performed:  24570 Read, 16380 Write, 52352 Other = 93302 Total
Read 383.91Mb  Written 255.94Mb  Total transferred 639.84Mb  (2.1327Mb/sec)
  136.50 Requests/sec executed

Test execution summary:
    total time:                          300.0103s
    total number of events:              40950
    total time taken by event execution: 230.0220
    per-request statistics:
         min:                                  0.03ms
         avg:                                  5.62ms
         max:                                692.52ms
         approx.  95 percentile:              13.96ms

Threads fairness:
    events (avg/stddev):           40950.0000/0.00
    execution time (avg/stddev):   230.0220/0.00

Conclusion

As you can see the transactions per second between the Western Digital Drive and the KEXIN Drive was more than 12.5% slower. The queries per second between the Western Digital Drive and KEXIN drive were more than 12.5% slower. Even the sysbench showed an extreme difference between the two drives. There is a 13.36ms difference in the 95% percentile. KEXIN:

transactions:                        34753  (231.62 per sec.)
queries:                             695060 (4632.45 per sec.)

Western Digital:

transactions:                        4356   (29.00 per sec.)
queries:                             87120  (579.94 per sec.)

With the cost of SSD drives dropping, we can see that the Raspberry Pi 4, 4GB with an SSD drive is a good choice for a small business (or anyone) that needs a good robust database at an affordable price range.
